| PV INPUT |
PIHY4600 – 4600 WATT (4.6kW) |
| Max Input Power (kW) |
6.9 |
| Max PV Voltage (V) |
660 |
| MPPT Range (V) |
80-550 |
| Normal Voltage |
360 |
| Startup Voltage |
100 |
| Max Input Current (A) |
15.5 x 2 |
| Max Short Current (A) |
26 x 2 |
| BATTERY PORT |
| Max Charge/Discharge Power (kW) |
6.9 | 6.9 |
| Max Charge/Discharge Current(A) |
50 |
| Battery Voltage (V) |
230 |
| Battery Voltage Range(V) |
80- 495 |
| Battery Type |
Lithium | Lead |
| AC GRID |
| Max Continuous Power(kVA) |
4.6 |
| Max Continuous Current(A) |
19.5 | 22.5 |
| Nominal Grid Voltage (V) |
211 to 264 @ 240 | 183 to 229 @ 208 (not 3 phase, split phase) |
| Nominal Grid Frequency (Hz) |
60 |
| Output Power Factor |
.99 adjustable |
| Current THD(%) |
<3 |
| AC BACK-UP & GENERATOR |
| Max Continuous Power(kVA) |
4.6 |
| Max Continuous Current(A) |
19.5 | 22.5 |
| Max Peak Currenty (A)(10 min) |
28.8 | 33.2 |
| Max Peak Power(kVA)(10 min) |
6.9 | 6.9 |
| Nominal AC Voltage L-L(V) |
240 | 208 (not 3 phase) |
| Nominal AC Voltage L-N(V) |
120 | 120 |
| Nominal AC Frequency(Hz) |
60 |
| Switching Time(ms) |
<10 |
| Voltage THD(%) |
<3 |
| EFFICIENCY |
| CEC Efficiency(%) |
97 |
| Max Efficiency(%) |
97.6 |
| PV to Battery Efficiency(%) |
98.1 |
| Battery to AC Efficiency(%) |
96.8 |
| PROTECTION |
| PV Reverse Polarity Protection |
YES |
| Battery Reverse Polarity Protection |
YES |
| Over Current/Voltage Protection |
YES |
| Anti-Islanding Protection |
YES |
| AC Short Circuit Protection |
YES |
| Residual Current Detection |
YES |
| Ground Fault Monitoring |
YES |
| Insulation Resister Detection |
YES |
| PV Arc Detection |
YES |
| Rapid Shut Down/Disconnect |
YES |
| Enclosure Protect Level |
IP65 | NEMA4X |
| GENERAL DATA |
| Cooling |
Natural Convection |
| Relative Humidity |
0-100% |
| Operating Temerature Range |
-25 to 60C | -77 to 140F |
| Operating Altitude |
< 4000 m | <13123 ft without derating |
| Noise Emission (dB) |
<25 |
| Stanby Consumption (W) |
<10 |
| Mounting |
Wall Bracket |
| Communication with RSD |
SUNSPEC |
| Display & Communication Interfaces |
Full Color LED, RS485, CAN, Wi-Fi |
| Certification & Approvals |
UL 1741 SA | CSA 2202 No. 107-01 |UL 1998 | Rules21 | HECO Rule 14 | IP65 | CEC |
| EMC |
FCC Part 15 Class B |
