Description
Use for on/off fluid control. Allows safer system operation by permitting relief of fluid pressure or isolation of components from pressure during maintenance. Ball vales must be used in the fully open or closed position. Do not throttle the valve – it could cause premature seal failure.
-
Stainless steel and PTFE materials are compatible with catalyst, waterborne, and other finishing materials
-
Many different connection options to meet your specific needs
UPC Product: 00633955820166 Family Code: FAMQFP Unit of Measure: EA Height: 1.55 IN |3.937 CM Length: 1.95 IN |4.953 CM Width: 5.35 IN |13.589 CM Volume: .009 FT3 |0 M3 Chargeable Weight: .55 LBS | .25 KG
Technical Specifications
| Handle Type | Lever |
|---|---|
| Inlet Size (cm) | 0.9525 |
| Inlet Size (in) | 3/8 |
| Inlet Size (mm) | 9.525 |
| Inlet Thread Type | NPT |
| Maximum Working Pressure (bar) | 21 |
| Maximum Working Pressure (kPa) | 2100 |
| Maximum Working Pressure (psi) | 300 |
| Outlet Size (cm) | 0.9525 |
| Outlet Size (in) | 3/8 |
| Outlet Size (mm) | 9.525 |
| Outlet Thread Gender | Female |
| Outlet Thread Type | NPT |
| Type | Ball Valve |
| Maximum Working Pressure (MPa) | 2.1 |
