Description
Baileigh 220V 3 Phase 224Ton 20ft 2 Axis Programmable Hydraulic Press Brake (1000790) delivers exceptional power and precision for industrial applications. With a capacity of 224 tons and a 10-foot length, this press brake is perfect for handling large-scale production runs. Its programmable control system ensures accuracy and efficiency.
This hydraulic press brake features a robust steel construction that minimizes deformation and ensures consistent performance. The Nachi® hydraulic pump and high-quality electrical components from Weidmueller and Schneider® guarantee long-lasting reliability.
- Specifications and Dimensions
- Length: 155 in.
- Width: 72 in.
- Height: 100 in.
- Net Weight: 29,570 lbs
- Table Length: 125/157″
- Back Gauge Length: 17144″
- Maximum Pressure: 224 tons
- Throat Depth: 12.5″
- Stroke Distance: 7″
- Approach Speed: 2.0″ / sec.
- Back Gauge Motor: 1/2 hp
- Bending Speed: .236″ / sec.
- Main Motor: 15 hp
- Distance Between Housings: 100/123″
- Distance From Table To Ram: 19.6″
- Power: 220V / 3-phase
- Key Features and Benefits
- Delivers 224 tons of pressure for heavy-duty applications
- Programmable control system with up to 40 programs and 25 bends per program
- Accurate bending to +/- .01mm ensures precision and consistency
- High-quality hydraulic components from Nachi® and electrical parts from Weidmueller and Schneider®
- Robust steel construction minimizes deformation and maintains accuracy
- User-friendly interface for easy operation and quick training
- 1-year parts warranty and lifetime technical support
- Ships fully assembled for quick setup
