Description
5175258 XPR-12CL-LTA BENDPAK 12K Capacity / Clearfloor / Long-Reach Triple-Telescoping Arms
If you need to service vehicles up to 12,000 lbs. capacity with extremely long wheelbases, BendPak’s XPR-12CL-LTA offers nearly 72 inches of reach, compared to 58 inches on our standard triple-telescoping arms. Ideal for hard-to-reach lift points that other two-post lifts cannot access.
Features
- 12,000-lb. lifting capacity
- CE Approved and Certified. Meets or exceeds the standards prescribed by European Standard EN 1493
- Padded overhead safety shutoff bar
- Extended height top-beam provides greater overhead clearance
- Single-point safety release
- Dual direct-drive hydraulic cylinders
- Dual-synchro equalization system for equal lifting
- Oversized 53″ tall carriage for superior strength and durability
- Electric / hydraulic power system
- Oversized A36 steel base plates
- Self-lubricating dura-glide UHMW polyethylene bearing system
- Safety locks in each column spaced every 3″
- Plated arm restraints and arm pins for rust prevention
- Heavy-duty 1/2″ aircraft-quality equalizer cables
- Oversized cable sheave diameter reduces cable fatigue
- Durable, rubber lift pads with stackable adapters
- 16-piece specialty adapter set includes four 6″ stackable adapters, four 3″ stackable adapters, four polyurethane contact pads and four frame cradle pads
- Convenient storage is included for truck and van adapters
- Long-reach triple-telescoping arms provide increased range for lifting point access
| Lifting Capacity* | 12,000 lbs. (5,443 kg) |
| *Max Capacity / Front Axle | 6,000 lbs. (2,722 kg) |
| *Max Capacity / Rear Axle | 6,000 lbs. (2,722 kg) |
| Rise | |
| A – Rise: | 69″ (1,753 mm) |
| B – Rise + Pad Only: | 74″ (1,880 mm) |
| C – Rise + Pad + 63 mm Adapter: | 80″ (2,032 mm) |
| D – Min. Height + Pad: | 5″ (127 mm) |
| Time to Full Rise: | 90 seconds |
| Outside Dimensions | |
| E – Height Overall: | 170″ (4,318 mm) |
| F – Width Overall: | 155″ (3,937 mm) |
| G – Outside Columns: | 144″ (3,658 mm) |
| Inside Dimensions | |
| H – Inside Columns: | 120″ (3,048 mm) |
| I – Drive-Thru Clearance: | 106″ (2,692 mm) |
| J – Floor To Overhead Switch: | 165″ (4,191 mm) |
| Arms & Pads | |
| K – Front Arm Reach: (MIN) | 37″ (940 mm) |
| K – Front Arm Reach: (MAX) | 72″ (1,829 mm) |
| L – Rear Arm Reach: (MIN) | 37″ (940 mm) |
| L – Rear Arm Reach: (MAX) | 72″ (1,829 mm) |
| Max Load Per Arm | 3,000 lbs. (1,361 kg) |
| Power Unit | |
| Motor: | 220 VAC / 60 Hz / 1 Ph |
| Noise: | 45 dB |
| Shipping | |
| Weight: | 2,724-lbs. (1,235.6 kg) |
| Dimensions: | 174” x 29” x 29” (4,419 mm x 736 mm x 736 mm) |
