Description
The Engineered Certified Industrial Jib Telehandler attachment is adjustable from 6’9″ to 12′. This jib manually adjust to 9 separate positions with different max lift capacities at each position (See chart below). The spring loaded adjustment pin makes changing positions quick and easy. This industrial jib meets ANSI and OSHA standards.
Lift Capacity Rating – * These lift capacity ratings are for the Industrial Jib only. The lifting capacity is ultimately determined by the host machine.
| JIB POSITION | LENGTH | MAX LIFT CAPACITY |
|---|---|---|
| 1 | 78″ | 6000 LBS |
| 2 | 86″ | 5715 LBS |
| 3 | 94″ | 5410 LBS |
| 4 | 102″ | 5075 LBS |
| 5 | 110.25″ | 4710 LBS |
| 6 | 118.50″ | 4320 LBS |
| 7 | 126.75″ | 3905 LBS |
| 8 | 135″ | 3465 LBS |
| 9 | 143.25″ | 3000 LBS |
