Description
Specifications
UPC Product: 755652299790Family Code: FAMEGSCountry of Origin: USUnit of Measure: EAHeight:22.5 IN|57.150 CMLength:15.5 IN|39.370 CMWidth:13.5 IN|34.290 CMVolume:2.725 FT3|0.077 M3Shipping Weight:36.8 LBS | 16.692 KG
Technical Specifications
| Engine Size (HP) | 0.75 |
|---|---|
| Fluid Outlet Size (mm) | 6.35 |
| Frame Configuration | Stand |
| Includes | SG3 Spray Gun, TrueAirless 515 Spray Tip, Spray Tip Guard, 1/4 in x 50 ft DuraFlex Hose, Pump Armor Storage Fluid (8 oz), Quick Start-Up Guide |
| Maximum Flow Rate (L/min) | 1.3 |
| Maximum Hose Length (ft) | 150 |
| Maximum Hose Length (m) | 45 |
| Maximum Tip Size (in) | 0.017 |
| Maximum Tip Size Gun 1 (in) | 0.017 |
| Maximum Working Pressure (psi) | 3000 |
| Maximum Working Pressure (kPa) | 20700 |
| Power Rating (HP) | 0.75 |
| Power Rating (kW) | 0.56 |
| Power Rating (W) | 559 |
| Maximum Working Pressure (MPa) | 20.7 |
| Pressure Control Type | Adjustable |
| Overall Width (mm) | 335 |
| Model | Magnum |
| Maximum Working Pressure (bar) | 207 |
| Overall Height (cm) | 53.9 |
| Overall Height (in) | 21.2 |
| Weight (kg) | 12 |
| Overall Height (mm) | 539 |
| Overall Length (cm) | 38.4 |
| Overall Width (in) | 13.2 |
| Overall Length (in) | 15.1 |
| Series | ProX17 |
| Overall Length (mm) | 384 |
| Overall Width (cm) | 33.5 |
| Recommended Annual Usage (gal) | 300 |
| Compatible Tip Size (in) | 0.009, 0.011, 0.013, 0.015, 0.017 |
| Outlet Paint Filter | InstaClean |
| Pump Mount Type | ProXchange |
| Pump Rod Type | Stainless Steel |
| Minimum Generator Power (W) | 2500 |
| Number of Guns | 1 |
| Amperage (A) | 8 |
| Product Series | Pro |
