Jet 10-PT 10T Plain Trolley Fits 4.75-8″ Wide Beam (252060)

Description

Jet 10-PT 10T Plain Trolley Fits 4.75-8″ Wide Beam (252060) is a heavy-duty manual trolley built for exceptional durability and smooth movement of loads up to 10 tons.

KEY FEATURES AND BENEFITS:

• High Capacity: Move heavyweight materials with confidence thanks to the 10-ton capacity.
• Beam Versatility: Works on wide-flange H-beams, standard I-beams, or curved tracks (minimum radius 67″).
• Durable Construction: Rugged steel side plates with built-in bumper guards ensure long-lasting performance and user safety.
• Effortless Movement: Hardened steel wheels with lubricated-for-life, double sealed ball bearings provide smooth rolling on various beams.
• Safety Compliance: Meets OSHA, ANSI/ASME B30.11, and B30.17 standards for safe operation.

SPECIFICATIONS:

• Capacity: 10 tons
• Beam Flange Width: 4-3/4″ to 8″
• Beam Height: 5″ to 19″
• Minimum Beam Curve Radius: 67″
• Height: 15.5″
• Width: 11.5″
• Length: 20″
• Weight: 211 lbs
• Manufacturer: Jet
• Model Number: 10-PT
• Part Number: 252060

HOW TO USE:

1. Select the appropriate beam: Ensure your beam meets the compatible width (4-3/4″ to 8″) and height (5″ to 19″) requirements. For curved tracks, verify the minimum radius is 67″ or greater.
2. Position the trolley: Open the trolley by squeezing the handle to expand the clamping mechanism. Place the trolley on the beam and release the handle for a secure fit.
3. Attach your hoist: The trolley features a flat top surface for securely attaching a compatible hoist (not included).
4. Maneuver your load: Use the hand pull chain on your hoist to raise or lower materials. The trolley allows for smooth horizontal movement along the beam.

BENEFITS OF USING Jet 10-PT 10T Plain Trolley Fits 4.75-8″ Wide Beam (252060):

• Efficiently move heavy machinery, equipment, and materials with minimal manual effort.
• Versatile design works on various beam types, maximizing usability in your workspace.
• Rugged construction ensures reliable performance and longevity, even in demanding applications.
• Promotes safe material handling by complying with industry safety standards.

FEATURES:

• Built-in bumper guards for enhanced user safety.
• Hardened steel wheels for smooth rolling and extended wear.
• Proof-tested with a certificate for assured quality.
