Description
All of the Magswitch Workholding System Attachments mount to theMagswitch Universal Baseand will work in combination with theMagswitch Workholding System Starter Kit.
| Attachment | ||
|---|---|---|
| Dual Roller Guide | Features a dual set of roller bearing supports for the firm yet smooth gliding of wood through a blade.Includes micro adjustment for fine tuning to 90 degrees.Ideal for re-sawing on band saws, as a a second hand to support raised/long or tall panels on table saws, or a general infeed outfeed support on tables or fences | |
| Resaw Guide | Features roller bearing support like the Dual Roller Guide for firm yet smooth gliding of wood through a blade.Angled Infeed/Outfeed to allow for blade drift adjustment.Ideal for resawing on band saws, oscillating spindle sander, or disc sander; and for infeed/outfeed support. | |
| Reversible Featherboard | Featherboard is reversible for left and right hand feeds. Accommodates the Vertical Featherboard Attachment for an added dimension of safety and protection against kickbacks. Low profile design for use on your smallest tables and fences. This attachment is included in theMagswitch Starter Kit. | |
| Thin Stock Jig & Rip Guide | Ideal for thin stock hold down or infeed/outfeed on a table saw.Designed with a stepped side for most common thickness of 1/8″, 1/4″ and 3/8″.The opposite side is sloped for odd sizes up to 3/4 inch.Features a fixed roller bearing and extends forward for accurate repetitive ripping of thin stock. Enhances safety by keeping fingers away from the blade while also minimizing chatter for clean cuts in thin stock. | |
| Universal Track – 36″ | Unlike any other extruded aluminum track on the market today, the Magswitch Track is truly universal.It accommodates all hardware on the market. Make your own Jigs, fixtures, stops, fences, zero clearance fences and more!Mounts to miter gauges and fences as well.Accepts all standard mounting hardware.One side accepts all standard T bolts and all 1/4″ hex.The other side accepts all standard T-bolts, all 5/16″ and Kreg® clamps.Includes micro adjustable brackets for fine tuning to 90 degrees.Comes in 18″ and 36″ lengths to accommodate small and large tables. | |
| Vertical FeatherBoard | When attached to thePro Table Featherboard, or Reversible Featherboard, the Vertical Featherboard Attachment can be mounted in a vertical position from the top for pressure down on the material at the same time the horizontal featherboard is holding the material against the fence.When set up in the stacked position using the risers, you double the featherboard hold on the same horizontal plane – ideal for tall material.This tool helps protect against kickbacks on both the vertical and horizontal planes. |
