Sump Alarm 120V 16‘ SludgeBoss w/ Power On Light (SA-120V-2L-16SB)

Description

The Sump Alarm 120V 16′ SludgeBoss w/ Power On Light (SA-120V-2L-16SB) is designed to provide timely and effective alerts for high water levels or pump malfunctions in outdoor pump systems and septic tanks. This system allows you to monitor critical liquid levels from the convenience and comfort of indoors, helping to prevent potential damage and costly repairs. Equipped with a power indicator light and a robust alarm system, the Sump Alarm offers peace of mind by keeping you informed of your system’s status.

KEY FEATURES AND BENEFITS:

• Early Warning System: Provides visual and audible alerts when a pump isn’t operating correctly or when high water levels are detected, allowing for prompt intervention.
• Indoor Monitoring: Enables convenient monitoring of outdoor systems from inside your home, ensuring you’re aware of any issues without needing to physically check the equipment.
• Highly Visible Alarm: Features a large, 1-inch red LED indicator light that is visible from a significant distance, ensuring you don’t miss a warning.
• Loud Audible Alert: Includes a 90dB directional horn that activates during a high-level alarm condition, providing an additional alert, especially when the visual indicator isn’t directly in sight. Remember to orient the horn towards your home for optimal audibility.
• Sludge Boss Float Switch: Comes with a 16-foot cord and a Sludge Boss float switch specifically designed for use in water containing sewage or significant floating debris. Its self-orienting design eliminates the need for a cable weight, ensuring reliable operation in challenging environments.

SPECIFICATIONS:

• Operating Voltage: 120V AC
• Alarm Sound Level: 90 dB
• Visual Indicator: 1-inch Red LED
• Power Indicator: 1-inch White LED
• Float Cable Length: 16 ft.
• Power Cord Length: 6 ft.
• Plug Type: 3-Prong Grounded
• Operating Temperature: -40°F to 140°F

HOW TO USE:

1. Secure the Sludge Boss Float Switch: Position the Sludge Boss float switch at the desired high-water level within your sump pit, septic tank, or other application. Use the provided zip ties to secure the float cable, ensuring the float can move freely within the operational range.
2. Mount the Head Unit: Choose a suitable indoor location to mount the Sump Alarm head unit where the indicator light and audible alarm can be easily seen and heard. Use the provided wall anchors and screws if mounting to a wall, or utilize the external feet for surface placement.
3. Plug in the Unit: Connect the 110V plug of the Sump Alarm into a standard 110V electrical outlet. The power indicator light should illuminate, confirming the unit is receiving power.
4. Test the Alarm (Optional): Carefully raise the Sludge Boss float switch to simulate a high-water level. The red LED indicator light should begin to flash, and the 90dB horn should sound. Lower the float to silence the alarm.
5. Monitor: Once installed, the Sump Alarm will continuously monitor the liquid level. In the event of a high water level or suspected pump failure leading to a rise in liquid, the alarm will activate.

BENEFITS OF USING THE SUMP ALARM 120V 16′ SLUDGEBOSS W/ POWER ON LIGHT (SA-120V-2L-16SB):

• Prevents Water Damage: Early detection of high water levels allows you to take corrective action before flooding and potential property damage occur.
• Reduces Repair Costs: By identifying pump failures or blockages quickly, you can address issues before they escalate into more expensive repairs or replacements.
• Provides Peace of Mind: Knowing that your pump system is being monitored, even from indoors, offers reassurance and reduces the need for frequent manual checks.
• Protects Your Investment: Safeguarding your property and equipment from water damage helps to protect your financial investment.
• Convenient Monitoring: The indoor monitoring capability saves time and effort, especially during inclement weather conditions.
• Reliable Performance: The Sludge Boss float switch is designed for dependable operation in challenging environments where standard floats may fail due to debris.

FEATURES:

• Power Indicator: A built-in power indicator light allows you to easily verify that the unit is receiving power, which can also help in identifying power issues with the pump on the same circuit.
• Simple Installation: Designed for easy, plug-and-play installation. Simply secure the Sludge Boss float, mount the head unit, and plug in the power cord.
• Mounting Hardware Included: Comes with external feet for surface mounting, wall anchors for head unit mounting, zip ties for securing the float switch cable, and comprehensive instructions.
• Versatile Application: Suitable for use in various applications, including sump pumps, water tanks, and lift stations.
• Configurable Alarm Type: While the unit is pre-wired for a high-level alarm, it can be rewired for a low-level alarm if required.
• Standard Power Connection: The 110 Volt unit is equipped with a standard 110V plug for easy connection to most household outlets.
