Description
Portable, drumless material hoist using 1⁄4 in. (6.5 mm) wire rope.
Includes 61⁄2 ft. (2 m) push button pendant control. Steel carrying box provided for TR 10 and TR 30 ONLY.
minifor® – TR10
Portable electric hoist with unlimited lifting height
FEATURES
- Portable and powerful for unlimited lifting height
- A complete range of electric hoists for a wide range of applications
- Lifting capacity of 220 lbs. (100 kg)
- Lifting speed 50 ft. per min (15 m/min)
- Can be doubled with a sheave kit
- Unlimited height of lift
- Optional rope reeler for TR10
- 61⁄2 ft. (2 m) pendant control
- Direct lift or sheaving kit for increased capacity
- Single phase or three phase power
- Comes with blue steel box
- Optional wireless remote control available
QUALITY AND POWER
- High power to weight ratio
- Body in aluminum alloy
- Unlimited length of lifting wire rope
- Wire rope, diameter of 1⁄4 in. (6.5 mm)*
- 115 V standard
SAFETY
- Upper and lower adjustable end limit stops
- Motor integrated brake
- Meets CSA and UL requirements
* Wire rope sold separately
220 V three phase models available upon request
Reelers of 60 and 110 ft. (18 and 33.5 m) available for TR10 and TR30
Optional wireless remote control available
Direct lift or sheaving kit available for increased capacity
